- UL recognized in the US and Canada
- 20kV peak rating guarantees quick and efficient ignition
- A vacuum encapsulation process, using epoxy, provides resistance to moisture, excellent heat dissipation and electrical insulation
- Epoxy potting will not shrink or crack like tar-filled transformers
- Case material is high-temperature thermoplastic that provides high impact strength, scratch resistance, impenetrable to oil and most chemicals
- Small size and weight (less than 1 lbs) — versus an 8 lbs iron core transformer, making shipping and installation easier
- Higher output voltage for more reliable ignition, especially with cold oil
- Adapts to multiple baseplates making it the most versatile unit on the market
Technical Specs
- Input Voltage: 208-240VAC, 50/60Hz, 21.6VA
- Output Voltage: 20kV peak
- Output Current: 25 mA RMS
- Secondary Mid-point Ground
- Ambient Operating Temperature: -40°F (-40°C) to 150°F (66°C)
- Storage Temperature: -40°F (-40°C) to 150°F (66°C)
- Moisture: 5 to 95% Relative Humidity
