Oil Seal; 1.75" x 2.50" x 0.31"
Regular price
$59.99 CAD
Couldn't load pickup availability
| Brand | Dichtomatik |
| Mfr. Description | DICHTOMATIK Rotary Shaft Seal | WBS | 44.45 X 63.55 X 7.95 / mm | 1750 X 2502 X 0313 //" | 70 NBR N701R |
| Mfr. Catalog Number | 75006821 |
Hercules® Sealing Products offers several sizes of standard sized metal clad oil seals. These seals are for rotating shafts and are specifically designed to prevent oil or grease leakage at maximum pressures of 10 PSI and temperature of 240 deg. F. Additional style and sizes are available upon request.
| SEAL INFORMATION | |
|---|---|
| MATERIAL | RUBBER |
| TEMPERATURE RANGE | -40° to +240° F |
| PRESSURE RANGE | 10 PSI MAXIMUM |
| SPEED | 3 FT/SEC |
| A Nom ID | 1-3/4 |
| B Nom OD | 2-1/2 |
| C Nom Height | 5/16 |
| G Housing Diameter | 2.502 |
| E Shaft Diameter | 1.750 |
| Material | NBR |
| Can Material | CARBON STEEL |
| Spring Material | CARBON STEEL |
| Temperature Range | -40° TO +240°F |
| Pressure Range | 10 PSI MAXIMUM |
| Speed | 3 FT/SEC |
OS-1.75x2.50x0.31TB
